Induktivni foto i sigurnosni senzori
SE Induktivni senzor XS6 M12 L50mm brass Sn4mm 12…24 VDC M12
Raspoloživost:
Nema na zalihama
Šifra proizvoda: XS612B3DAM12
7.223,00 RSD
Nema na zalihama
| range of product | Telemecanique Inductive proximity sensors XS |
|---|---|
| series name | General purpose |
| sensor type | Inductive proximity sensor |
| sensor name | XS6 |
| sensor design | Cylindrical M12 |
| size | 50 mm |
| body type | Fixed |
| detector flush mounting acceptance | Flush mountable |
| material | Metal |
| type of output signal | Discrete |
| wiring technique | 2-wire |
| [Sn] nominal sensing distance | 4 mm |
| discrete output function | 1 NO |
| output circuit type | DC |
| electrical connection | Male connector M12, 4 pins |
| [Us] rated supply voltage | 12…24 V DC with reverse polarity protection |
| switching capacity in mA | <= 100 mA DC with overload and short-circuit protection |
| IP degree of protection | IP67 conforming to IEC 60529 IP69K conforming to DIN 40050 |
