J-H(St)H Lg |
||||||||||||||||||||||||||||||
Application Cable Construction | ||||||||||||||||||||||||||||||
· In places where human life, valuable materials and | ||||||||||||||||||||||||||||||
equipments need to be protected. | ||||||||||||||||||||||||||||||
· In crowded indoor environments. | ||||||||||||||||||||||||||||||
· At instrumentation and control engineering. | ||||||||||||||||||||||||||||||
· At industrial electronics. | ||||||||||||||||||||||||||||||
· Computer and office devices. | ||||||||||||||||||||||||||||||
· Indoor communication systems. | ||||||||||||||||||||||||||||||
· Indoor sound systems. | ||||||||||||||||||||||||||||||
· Security and fire alarm systems. | ||||||||||||||||||||||||||||||
1 – Conductor : Class 1 electrolytic solid copper (IEC 60228, DIN VDE | ||||||||||||||||||||||||||||||
0295, EN 60228) | ||||||||||||||||||||||||||||||
2 – Insulation : HFFR compound (VDE 0815, EN 50290-2-26) | ||||||||||||||||||||||||||||||
3 – Stranding : Two pairs are stranded into a star-quad, above two pairs are stranded together in layers. | ||||||||||||||||||||||||||||||
4 – Wrapping : Polyester tape | ||||||||||||||||||||||||||||||
5 – Screen : Tinned copper earthing wire, Al/PET tape | ||||||||||||||||||||||||||||||
6 – Outer Jacket : UV resistant halogen-free outer jacket. RAL 3000 (Red) | ||||||||||||||||||||||||||||||
Technical Characteristics | ||||||||||||||||||||||||||||||
Conductor Diameter | Conductor Resistance Ω/km (20 °C) | Insulation Resis- tance MΩ/km (500 V DC) |
Mutual Capacitance nF/km (800 Hz) |
Operating Voltage V DC | Test Voltage V (DC, 1 minute) |
|||||||||||||||||||||||||
0.60 mm | 130 | 100 | 100 | 300 | 800 | |||||||||||||||||||||||||
0.80 mm | 73.2 | 100 | 100 | 300 | 800 | |||||||||||||||||||||||||
1.00 mm | 44.6 | 100 | 100 | 300 | 1000 | |||||||||||||||||||||||||
1.5 mm² | 24.6 | 100 | 100 | 300 | 1000 | |||||||||||||||||||||||||
2.5 mm² | 15.1 | 100 | 100 | 300 | 1000 | |||||||||||||||||||||||||
Mechanical Characteristics | ||||||||||||||||||||||||||||||
Bending Radius | Temperature Range Operating | |||||||||||||||||||||||||||||
10xD mm | -30°C~+70°C | |||||||||||||||||||||||||||||
Standards | ||||||||||||||||||||||||||||||
Smoke Density Test | Corrosive Gas Test | Halogen-free Test | Flame Retardancy Test | Flame Propagation Test | ||||||||||||||||||||||||||
IEC 61034-2, VDE 0482-1034-2, EN 61034-2 |
IEC 60754-2, VDE 0482-267-2-3, EN 50267-2-3 |
IEC 60754-1, VDE 0482-267-2-1, EN 50267-2-1 |
IEC 60332-3-24, VDE 0482-332-3-24, EN 60332-2-24 |
IEC 60332-1-2, VDE 0482-332-1-2, EN 60332-1-2 |
||||||||||||||||||||||||||
Notes | ||||||||||||||||||||||||||||||
Reference Standard: DIN VDE 0815, TSEK | ||||||||||||||||||||||||||||||
F008 | ||||||||||||||||||||||||||||||
J-H(St)H Lg | ||||||||||||||||||||||||||||||
Part Number | Pair Count | Conductor Diameter (mm) | Approx. Cable Diameter (mm) | Copper Weight (kg/km) | Approx. Weight (kg/km) | Packing Lengths (m) | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0001 | 1 | 0.6 | 4.1 | 7.2 | 22 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0002 | 2 | 0.6 | 4.7 | 12.5 | 32 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0003 | 3 | 0.6 | 6.1 | 17.8 | 46 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0004 | 4 | 0.6 | 7.2 | 23.1 | 58 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0005 | 5 | 0.6 | 7.5 | 28.4 | 69 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0006 | 6 | 0.6 | 9.1 | 33.7 | 84 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0008 | 8 | 0.6 | 9.3 | 44.3 | 101 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0010 | 10 | 0.6 | 9.7 | 54.9 | 119 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0012 | 12 | 0.6 | 10.4 | 65.6 | 138 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0014 | 14 | 0.6 | 11.3 | 76.2 | 162 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0016 | 16 | 0.6 | 11.9 | 86.8 | 180 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0020 | 20 | 0.6 | 13.3 | 108 | 218 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0024 | 24 | 0.6 | 14.3 | 129.2 | 259 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0025 | 25 | 0.6 | 14.5 | 134.5 | 268 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0030 | 30 | 0.6 | 18.8 | 161.1 | 339 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0040 | 40 | 0.6 | 20.8 | 214.1 | 428 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0050 | 50 | 0.6 | 23 | 267.2 | 518 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0060 | 60 | 0.6 | 25.1 | 320.2 | 620 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0080 | 80 | 0.6 | 28.1 | 426.3 | 792 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0060.0.0100 | 100 | 0.6 | 32.1 | 532.4 | 986 | 100/500/1000 | ||||||||||||||||||||||||
Part Number | Pair Count | Conductor Diameter (mm) | Approx. Cable Diameter (mm) | Copper Weight (kg/km) | Approx. Weight (kg/km) | Packing Lengths (m) | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0001 | 1 | 0.8 | 4.6 | 11.3 | 29 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0002 | 2 | 0.8 | 5.3 | 20.7 | 44 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0003 | 3 | 0.8 | 6.9 | 30.2 | 65 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0004 | 4 | 0.8 | 8.1 | 39.6 | 82 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0005 | 5 | 0.8 | 8.6 | 49.1 | 98 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0006 | 6 | 0.8 | 10.4 | 58.5 | 119 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0008 | 8 | 0.8 | 10.7 | 77.3 | 145 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0010 | 10 | 0.8 | 11.1 | 96.2 | 173 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0012 | 12 | 0.8 | 11.8 | 115.1 | 199 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0014 | 14 | 0.8 | 12.8 | 133.9 | 233 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0016 | 16 | 0.8 | 13.5 | 152.8 | 261 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0020 | 20 | 0.8 | 15.2 | 190.5 | 318 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0024 | 24 | 0.8 | 16.2 | 228.3 | 379 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0025 | 25 | 0.8 | 16.5 | 237.7 | 391 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0030 | 30 | 0.8 | 21.3 | 284.8 | 482 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0040 | 40 | 0.8 | 23.8 | 379.2 | 629 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0050 | 50 | 0.8 | 26.4 | 473.5 | 766 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0060 | 60 | 0.8 | 28.8 | 567.8 | 918 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0080 | 80 | 0.8 | 32.3 | 756.4 | 1184 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0080.0.0100 | 100 | 0.8 | 36.8 | 945.1 | 1458 | 100/500/1000 | ||||||||||||||||||||||||
F009 | ||||||||||||||||||||||||||||||
J-H(St)H Lg | ||||||||||||||||||||||||||||||
Part Number | Pair Count | Conductor Diameter (mm) | Approx. Cable Diameter (mm) | Copper Weight (kg/km) | Approx. Weight (kg/km) | Packing Lengths (m) | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0001 | 1 | 1 | 5.5 | 19.6 | 42 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0002 | 2 | 1 | 6.3 | 34.4 | 65 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0003 | 3 | 1 | 8.1 | 49.5 | 92 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0004 | 4 | 1 | 9.6 | 64.3 | 117 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0005 | 5 | 1 | 10.1 | 79.2 | 140 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0006 | 6 | 1 | 12.3 | 94.1 | 170 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0008 | 8 | 1 | 12.7 | 123.9 | 212 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0010 | 10 | 1 | 13.1 | 153.6 | 251 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0012 | 12 | 1 | 14 | 183.4 | 290 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0014 | 14 | 1 | 15.2 | 213.1 | 339 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0016 | 16 | 1 | 16.1 | 242.9 | 381 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0100.0.0020 | 20 | 1 | 18 | 302.4 | 465 | 100/500/1000 | ||||||||||||||||||||||||
Part Number | Pair Count | Conductor Cross-section (mm²) | Approx. Cable Diameter (mm) | Copper Weight (kg/km) | Approx. Weight (kg/km) | Packing Lengths (m) | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0001 | 1 | 1.5 | 6.8 | 32.2 | 64 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0002 | 2 | 1.5 | 7.8 | 59.6 | 105 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0003 | 3 | 1.5 | 10.2 | 87.4 | 151 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0004 | 4 | 1.5 | 12.5 | 114.9 | 201 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0005 | 5 | 1.5 | 13.1 | 142.4 | 238 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0006 | 6 | 1.5 | 16.2 | 170 | 297 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0008 | 8 | 1.5 | 16.9 | 225 | 377 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0150.0.0010 | 10 | 1.5 | 17.4 | 280 | 448 | 100/500/1000 | ||||||||||||||||||||||||
Part Number | Pair Count | Conductor Cross-section (mm²) | Approx. Cable Diameter (mm) | Copper Weight (kg/km) | Approx. Weight (kg/km) | Packing Lengths (m) | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0001 | 1 | 2.5 | 7.8 | 49.7 | 90 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0002 | 2 | 2.5 | 9 | 94.5 | 151 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0003 | 3 | 2.5 | 11.9 | 140 | 219 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0004 | 4 | 2.5 | 14.5 | 185 | 289 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0005 | 5 | 2.5 | 15.1 | 230.1 | 346 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0006 | 6 | 2.5 | 18.9 | 275.1 | 429 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0008 | 8 | 2.5 | 19.7 | 365.2 | 549 | 100/500/1000 | ||||||||||||||||||||||||
3.644.1.3.3.0250.0.0010 | 10 | 2.5 | 20.3 | 455.3 | 660 | 100/500/1000 | ||||||||||||||||||||||||
F010 |
