Kabl Cat 5e U/UTP PVC

Raspoloživost:

Na zalihama
Šifra proizvoda: E02736
Dodaj u listu
Uporedi

53,00 RSD

Na zalihama

Data/LAN Cables
Cat 5e U/UTP PVC
Application                                          Cable Construction
· 10 BASE-T (IEEE 802.3) Ethernet
. 100 BASE-T (IEEE 802.3u) Fast Ethernet
· 100 VG-AnyLAN (IEEE 802.12)
· 4/16 Mbps Token Ring (IEEE 802.5)
· 100 Mbps CDDI
. 52/155 Mbps ATM
· 1000 BASE-T (Gigabit Ethernet) (IEEE 802.3 ab)
. In places where human life, valuable materials and equipments need to be protected.
1 – Conductor     : Electrolytic solid copper conductor. 2 – Insulation      : Solid polyethylene insulation
3 – Stranding      : Insulations are stranded into pairs and all pairs are stranded together.
4 – Outer Jacket  : UV resistant PVC outer jacket. RAL 7035 (Grey)
        Technical Characteristics
Conductor Resistance Ω/km Insulation Resistance
MΩxkm (500 V DC)		 Mutual Capacitance nF/km Capacitance Unbalance Propaga- tion Velocity Operating Voltage
V		 Test Voltage V Characteristic Impedance
Ω
94 5000 56 %2 %67-69 250 1200 100±%15. 1-100 MHz
        Mechanical Characteristics
Bending Radius Temperature Range Operating
8xD mm -20°C~+60°C
        Standards
Manufacturing Std. Flame Retardancy Test
ANSI/TIA-568-C.2.
IEC-61156-5. IEC-11801		 IEC 60332-1-2.
VDE 0482-332-1-2.
EN 60332-1-2
        Electrical Properties
Frequency MHz Insertion Loss dB/100m (Max.) Near-end Crosstalk (NEXT) Loss
dB (Min.)		 Power-sum Near-end Crosstalk (PSNEXT) Loss dB (Min.) Equal-level Far-end Crosstalk (ELFEXT) dB/100m (Min.) Power-sum Equal Level Far-end Crosstalk (PSELFEXT) dB/100m (Min.) Return Loss (RL) dB (Min.)
0.772 1.8 67 64 66 66 –
1 2 65.3 62.3 63.8 63.8 23
4 4.1 56.3 53.3 51.8 51.8 23
8 5.8 51.8 48.8 45.7 45.7 23
10 6.5 50.3 47.3 43.8 43.8 23
16 8.2 47.2 44.2 39.7 39.7 23
20 9.3 45.8 42.8 37.8 37.8 23
25 10.4 44.3 41.3 35.8 35.8 22
31.25 11.7 42.9 39.9 33.9 33.9 21
62.5 17 38.4 35.4 27.9 27.9 18
100 22 35.3 32.3 23.8 23.8 16
               Cat 5e U/UTP 24 AWG PVC
Part Number Pair Count Conductor Diameter (mm) Approx. Cable Diameter (mm) Copper Weight (kg/km) Approx. Weight (kg/km) Packing Lengths (m)
3.415.2.1.2.0051.0.0004 4 0.51 5.4 15.9 35 100/500/1000

Cena za 1m
