Provodnik JE-H(St)H FE180 / E90 2x2x0.8mm²

Provodnik JE-H(St)H FE180 / E90 2x2x0.8mm²

105,00 RSD

Na zalihama

Šifra proizvoda: E07627 Kategorija: Proizvođač:
  • Opis
  • Dokumentacija (1)
Electronic Control Cables
Fire Resistant Cables



JE-H(St)H Bd (FE180 / E30-E90 / PH120)

Application                                         Cable Construction
· Feeder cable for frequency controlled motors with electromagnetic interference.
· At instrumentation and control engineering.
· At industrial electronics.
· Computer and office devices.
· Indoor communication systems.
· Indoor sound systems.
· In places where human life, valuable materials and equipments need to be protected.
1 – Conductor     : Class 1 electrolytic solid copper (IEC 60228, DIN VDE 0295, EN 60228)
2 – Insulation      : Cross-linked polymer compound in ceramic form (VDE 0815)
3 – Stranding       : Insulations are stranded into pairs, four pairs are stranded together into groups, groups are stranded in layers.
4 – Wrapping     : Polyester tape, glass yarn tape
5 – Screen         : Tinned copper earthing wire, Al/PET tape
6 – Outer Jacket  : UV resistant halogen-free outer jacket. RAL 2008 (Orange)
         Technical Characteristics
Conductor Diameter Conductor Resistance Ω/km (20 °C) Insulation Resistance MΩ/km (500 V DC) Mutual Capacitance nF/km
(800 Hz)
Operating Voltage V DC Test Voltage V (DC,
1 minute)
0.60 mm 130 100 100 300 1000
0.80 mm 73.2 100 100 300 1000
1.00 mm 44.6 100 100 300 1000
1.5 mm² 24.6 100 100 300 1000
2.5 mm² 15.1 100 100 300 1000
         Mechanical Characteristics
Bending Radius Temperature Range Operating
10xD mm -40°C~+70°C
         Standards
Smoke Density Test Corrosive Gas Test Halogen-free Test Flame Retardancy Test Flame Propagation Test
IEC 61034-2,
VDE 0482-1034-2,
BS EN 61034-2
IEC 60754-2,
VDE 0482-267-2-3,
BS EN 50267-2-3
IEC 60754-1,
VDE 0482-267-2-1,
EN 50267-2-1,
BS EN 50267-2-1
IEC 60332-1-2,
VDE 0482-332-1-2,
BS EN 60332-1-2
IEC 60332-3-24,
VDE 0482-332-3-24,
BS EN 60332-3-24
Circuit Integrity Test (FE180) Circuit Integrity with Shock Test (PH120) Cable System Circuit Integrity Test (E30 / E60 / E90)
IEC 60331-23 EN 50200, VDE 0482-200, BS EN 50200 DIN 4102-12 E30 / E90
Notes
Reference Standard: DIN VDE 0815
G006
                JE-H(St)H Bd (FE180 / E30-E90 / PH120)
Part Number Pair Count Conductor Diameter (mm) Approx. Cable Diameter (mm) Copper Weight (kg/km) Approx. Weight (kg/km) Packing Lengths (m)
3.650.1.4.3.1080.0.0001 1 0.8 5.4 14.3 38 100/500/1000
3.650.1.4.3.1080.0.0002 2 0.8 6.2 23.8 54 100/500/1000
3.650.1.4.3.1080.0.0003 3 0.8 7.9 33.4 80 100/500/1000
3.650.1.4.3.1080.0.0004 4 0.8 9.5 42.9 103 100/500/1000
3.650.1.4.3.1080.0.0005 5 0.8 9.8 52.4 119 100/500/1000
3.650.1.4.3.1080.0.0006 6 0.8 11.9 62 144 100/500/1000
3.650.1.4.3.1080.0.0008 8 0.8 12.3 81 178 100/500/1000
3.650.1.4.3.1080.0.0010 10 0.8 12.8 100.1 208 100/500/1000

 Cena je za 1m

Preuzmite katalog proizvoda JE-H(St)H Bd (FE180 - E30-E90 - PH120)
